Pneumatic Air Jack APK-4000

The APK-4000 Air Jack is a basic model designed for point lifting vehicles weighing up to 4 tons. Equipped with two short handles, it is perfect for use in confined spaces. Thanks to its compact design, the jack is easy to transport and fits in most car trunks without the need for disassembly.

Height Range

• Maximum lifting height: 40 cm
• Resting height: 15 cm

Power Supply

The jack is powered by compressed air with a working pressure of 6 to a maximum of 10 bar.

Features and Functionality

The simple and robust design ensures reliable operation, making this jack an excellent tool for quickly lifting a vehicle, for example, to change a wheel. Key features highlighting its high quality and functionality include:

• Steel construction with detachable handles,
• Durable powder-coated finish in graphite color, providing corrosion resistance,
• 3-level rubber bellows made from durable rubber,
• Internal stabilizing telescopic guide for additional stability,
• Two short handles for easy carrying and maneuvering in tight spaces,
• Anti-slip grips made of grooved rubber,
• 3/8” ball valves with levers marked by color: green (supply) and red (release),
• Safety valve preventing the air bag from bursting in case of excessive air pressure,
• Rubber foot to prevent the lifted element from slipping.

Additional Protective Pad

In addition to the standard, screwed-on rubber support foot, the jack comes with an additional protective rubber pad. The pad, with a diameter of 180 mm, completely covers the surface of the top plate. This provides effective protection for the lifted vehicle against scratches caused by manipulating the jack under the lifting point, as well as in the event of the vehicle slipping off the standard foot.

Safety of Use

The construction and design of the jack comply with occupational health and safety standards, and the device is certified with the EU Declaration of Conformity.
